Xtreme 025 3805-2Z/CSB
d (Bore diameter) mm
25.0
D (Outside diameter) mm
37.0
B (Width) mm
10.0
Ring Material
Chromium Steel (SAE 52100)
Seals
2Z
Cage
PA66 (TN9)
Load Rating Dynamic (C) [kN]
5.9
Load Rating Static (C0) [kN]
4.4
Radial Clearance
CN
Limiting Speed (rpm)
21000.0
Item Number
112072
Category
Angular Contact Ball Bearings
Contact Angle
25
Ball Material
Silicon Nitride (Si3N4)
