Double Row ACBB

Unleash the Power of Double Row Angular Contact Ball Bearings for Unmatched Performance

Enhance Performance with Double Row Angular Contact Ball Bearings Featuring Ceramic Balls

Discover the power and adaptability of Double Row Angular Contact Ball Bearings (ACBB) with ceramic balls, designed to handle both radial and axial loads simultaneously with greater efficiency. These high-performance bearings feature a unique configuration that enhances durability and precision, making them ideal for demanding applications.

Filter

85 Produkte

d
12.0
15.0
15.0
17.0
17.0
17.0
20.0
20.0
20.0
25.0
25.0
30.0
45.0
10.0
12.0
15.0
15.0
17.0
17.0
17.0
17.0
20.0
20.0
20.0
D [mm]
32.0
35.0
35.0
40.0
40.0
40.0
47.0
47.0
52.0
52.0
52.0
62.0
85.0
30.0
32.0
35.0
42.0
40.0
40.0
40.0
47.0
47.0
47.0
47.0
B
16.0
16.0
16.0
18.0
18.0
18.0
21.0
21.0
22.0
21.0
21.0
24.0
30.0
14.0
16.0
16.0
19.0
18.0
18.0
18.0
22.0
21.0
21.0
21.0
C [kN]
10.1
11.2
11.2
14.3
14.3
14.3
20.4
20.4
24.5
22.0
22.0
20.4
52.0
7.61
10.1
11.2
15.1
14.3
14.3
14.3
21.6
20.4
20.4
20.4
C0 [kN]C0 [kN]
4.48
5.44
5.44
7.04
7.04
7.04
10.32
10.32
12.48
12.24
12.24
11.2
33.2
3.44
4.48
5.44
7.44
7.04
7.04
7.04
10.16
10.32
10.32
10.32

d = Inner ring dimension
D = Outer ring dimension
B = Bearing width

Unleash the Power of Double Row Angular Contact Ball Bearings for Unmatched Performance

1. Superior Load Handling

Double Row ACBBs are designed to efficiently manage both radial and axial loads in two directions, offering greater strength compared to single-row designs. The ceramic balls reduce weight and friction, improving performance under higher speeds and load conditions.

2. Variable Contact Angles for Enhanced Performance

Depending on the specific series and design, these bearings come with contact angles of 15°, 25°, 30°, and 40°, allowing you to select the ideal balance between axial load capacity and speed. Larger angles provide superior axial load support, while smaller angles enable higher speed performance.

3. Ceramic Balls for Lower Friction and Higher Speed

The use of ceramic balls significantly reduces friction and heat generation, allowing for higher rotational speeds and greater wear resistance. This makes them particularly useful in high-speed or high-temperature environments.

4. Double Row Configuration for Stability

The double-row design provides greater stability, improving the bearing’s capacity to handle misalignment and tilting moments. This configuration also enhances load distribution, making it ideal for applications where precision and durability are critical.

5. Material and Tolerance Options

Choose from a variety of cage materials including steel, polymer, or brass, along with a range of tolerance classes to meet specific application needs. The ceramic balls add an additional layer of durability, especially in high-performance environments.

6. Applications Across Multiple Industries

Double Row ACBBs with ceramic balls are widely used in sectors such as aerospace, automotive, machine tools, electric motors, and high-speed spindles. Their ability to perform under extreme conditions makes them a go-to solution for precision engineering tasks.

Enhance the performance and lifespan of your machinery with our high-quality Double Row Angular Contact Ball Bearings with ceramic balls, designed for optimal efficiency and reliability across a wide range of applications.
